Mercedes Benz Sprinter Ambulance

Vehicle Specifications:

Vehicle type:324 KA (Petrol Version, Automatic Gear Box)
Body Type: Panel Van
Engine Power: 190 kW (258 HP), 6 Cylinder, 3500 CC, 3.5 Litre
Loading Space: 3365/1780/1940 mm (L/W/H interior)
Wheelbase: 3665mm
Gross Vehicle Weight: 3880 kgs.
Tire Size: 2 x RH2 – Tyres 235/65 R16 C
Steering /Drive train: LEFT HAND DRIVE, 4×2

Ambulance Specifications:

• Sub-structure, Insulation, Reinforcement of Patient’s Cabin.
• Marine Plywood Flooring with Vinyl Coating (Waterproof).
• Complete Ceiling System.
• Roof Type Ventilation Fan.
• Bulk Head (Partition Wall) with Sliding Window.
• Compartment’s air-conditioning holes fixed in the ceiling with not less than three holes from each side with a stainless steel rod fixed in the center of the ceiling.
• Heater in Patients Cabin.
• Air Conditioning System for the Patient’s Cabin (Evaporator) +Roof Type Condenser
  Additional A/C with separate compressor from vehicle.
• Well designed ceiling mounted one way extractor which eliminates air and odors from the patient compartment and disposes them outside the ambulance. Nominal Voltage.
• Electrical Wiring with Insulation.
• Electrical Control Panel/ Fuse Box.
• 3 Electrical Outlets (12V)
• 2 Electrical Outlets (220V)
• Inverter +Extra Battery
• Inboard Battery Charger
• 2 Oxygen Regulator with Manometer -Amico,Canada
• 2 Humidifier and Oxygen Flowmeter
• Advance Electronic Touch Screen -Wifi Control Panel
• Intercom Set ,communication between Driver and Patient’s Cabin
• Cabinets for Medical Equipment’s and Electrical Outlets
• The cabinets are constructed of ABS material with High Impact Strength, low flammability, Good Sound &
• Thermal Insulation, Non Corrosive and Resistance to Oscillation & Vibration . Equipped with storage for medication and consumables.
• Flamethrower
• water and connect it to the flow-meter plus check for proper connection.
• Shoreline Outlet- 220 volts input with socket and plug and extension
• 2x Oxygen Outlet -Amico,Canada
• Oxygen Cylinder Exchange Valve
• Oxygen Pressure Gauge
• Oxygen System related hoses
• On-Board Internal Suction Pump with Suction Gauge, Regulator and 1Ltr Autoclaveable Suction Jar
• General & Complete various LED Lighting of Patient’s Cabin
• Complete Covering of Patient’s Cabin
• Siren System, Amplifier and Microphone
• Public Address Alarm and Slim Type LED Lightbar
• 2 Strobe LED Lights
• Flood Light, rear of ambulance
• Single fold-able seat, with swiveling mechanism, adjustable headrest, 3 point automatic safety belt (European standards).
• 1x Foldable Attendant Seat
• 1x Technician’s Seat
• LED Warning Lights, each sides of ambulance (2, both sides)
• Signal Light
• Grill Light
• An adjustable floodlight fitted above the rear door of the patient compartment to illuminate the area during the stabilization and loading of a patient.
• Long Grab Handle
• Made of stainless tube mounted on the ceiling.
• Short Grab Handle
• Electric Side Step – Stem, Italy
• 2x I.V. Hooks
• Emergency Hammer with Seat Belt Cutter
• Rear Camera with Monitor
• Fire Extinguisher (2kg)
• Glass Tinting of Ambulance
• Waste Bin
• Wall Mounted Sphygmomanometer
• Livery, Designing of Ambulance body

Medical Equipment’s:
Roll-in Chair Cot ( New Cavalier) – Automatic Loading
Portable Suction PS154A, Rechargeable (AC/DC)
Emergency Backpack FABP with resuscitation set
